Hikvision DS-PWA32-K Wireless Control Panel Kits
Categories: , Tag: Brand:

Hikvision DS-PWA32-K Wireless Control Panel Kits

KSh16,130

  • Supports up to 32 wireless inputs, 4 wireless output expanders
  • Offers multiple communication methods: LAN + Wi-Fi
  • Up to 2-ch. on-board video verification
  • Offers reliable protection utilizing two-way wireless technology
  • Wireless connection reduces installation time
  • Communicates up to 800 m (in open areas)
  • Contains DS-PWA32-H (White, 433MHz) x 1
  • DS-PD2-P10P-W x 1
  • DS-PD1-MC-WWS x 1
  • DS-19K00-Y x 1
Add to Wishlist
Add to Compare
Share it:
Compare
  • Detection performance
  • Detection Range10m(DS-PD2-P10P-W(433MHz))
  • Detection Angle85°(DS-PD2-P10P-W(433MHz))
  • Velocity range0.3m/s ~ 3.0m/s(DS-PD2-P10P-W(433MHz))
  • Pet Immunity24kg(DS-PD2-P10P-W(433MHz))
  • Software features
  • Partition4
  • Onboard video clipsUp to 2-ch onboard video
  • Tamper-ProofTampering alarm(DS-PWA32-HSR(433MHz) Front, rear, and bracket tamper signal input(DS-PD2-P10P-W(433MHz)) Front and rear(DS-PD1-MC-WWS(H)(433M)）
  • ScheduleAuto Arm/Disarm Schedule
  • SMS notificationSupport
  • Phone call notificationSupport
  • Phone numbers8
  • Signal strength indicationSignal Strength Indicators (SSI)
  • Firmware undate toolsWeb client / iVMS-4200 / Hik-Connect
  • Configuration toolsWeb client / iVMS-4200 / Hik-Connect
  • ApplicationiVMS-4200, and mobile APP
  • ProtocolSIA – Contact ID; EHome v5.0
  • IC Card5
  • User13 (1 installer, 1 administrator, and 11 general user)
  • Hardware features
  • Alarm input32
  • Alarm output32
  • IndicatorLED
  • RF transmission
  • RF Frequency433MHz
  • RF Modulation2GFSK(DS-PWA32-HSR(433MHz)） FSK(DS-19K00-Y(433MHz)）
  • RF Speed10kbps（DS-19K00-Y(433MHz)、DS-PD1-MC-WWS(H)(433M)）
  • RF Range800m (Open Area)(DS-PWA32-HSR(433MHz)、DS-PD2-P10P-W(433MHz)、DS-PD1-MC-WWS(H)(433M)）300m (Open area)（DS-19K00-Y(433MHz)）
  • Electrical characteristics
  • Power supply5 VDC，10 W(DS-PWA32-HSR(433MHz) CR2032 3.0V, 2-year power supply（DS-19K00-Y(433MHz)）
  • Battery type4520 mAh lithium backup battery(DS-PWA32-HSR(433MHz) 1×CR123A(DS-PD2-P10P-W(433MHz)) 1×CR123A, 3.0V(DS-PD1-MC-WWS(H)(433M)）,CR2032 3.0V(DS-19K00-Y(433MHz))
  • Battery life spanRechargeable lithium battery, supports up to 12h power supply(DS-PWA32-HSR(433MHz) 2 years Battery life (DS-PD2-P10P-W(433MHz)、(DS-PD1-MC-WWS(H)(433M)）、（DS-19K00-Y(433MHz)）
  • Power Consumption< 5.6 W
  • Wireless transmission
  • Wired network10M/100M Self-adaptive
  • Network encryptionAES-128 encryption
  • Wi-Fi Standard802.11b/g/n
  • Wi-Fi EncryptionSupported
  • Wi-Fi Channel2.4 G
  • General
  • Operation temperature–10 °C to 55 °C(DS-PWA32-HSR(433MHz)、DS-PD1-MC-WWS(H)(433M)、DS-19K00-Y(433MHz)） ‘-10℃~+40℃ (DS-PD2-P10P-W(433MHz))
  • Operation humidity10% to 90%
  • Shell materialPC+ABS
  • Dimension(WxHxD)155 × 155 × 35mm(DS-PWA32-HSR(433MHz)) 117mm× 69mm× 50mm (DS-PD2-P10P-W(433MHz)) 84mm x 25mm x 20.99mm(DS-PD1-MC-WWS(H)(433M)）63mm x 49mm x 16mm(DS-19K00-Y(433MHz))
  • 125g (DS-PD2-P10P-W(433MHz)) 37g(DS-PD1-MC-WWS(H)(433M)） 24.5g(DS-19K00-Y(433MHz))
  • Application scenarioindoor
  • ColorWhite
  • Installation height1.8m ~ 2.4m(DS-PD2-P10P-W(433MHz))
  • BracketIncluding 1 x Ceiling mounting bracket, 1 x Wall mounting bracket,used by DS-PD2-P10P-W(435MHz)
  • Audio
  • Audio output1, 1.5W
  • Device management
  • Keyfob8
  • Wireless siren4
  • Tag reader4
  • Keypad4
