- Recording
- Encoding resolution
When 1080p lite mode is not enabled: 720p/WD1/4CIF/VGA/CIF
When 1080p lite mode is enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF
- Video bit rate32 Kbps to 4 Mbps
- Video compressionH.264+/H.264
- Dual streamSupport
- Stream typeVideo, Video & Audio
- Audio compressionG.711u
- Audio bit rate64 Kbps
- Video and Audio
- Audio input1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio output1-ch, RCA (Linear, 1 KΩ)
- Synchronous playback8-ch
- IP video input2-ch (up to 10-ch);Up to 960P resolution;Support H.264+/H.264 IP cameras
- HDTVI input
1080p25, 1080p30, 720p25, 720p30
- HDCVI input1080p25, 1080p30, 720p25, 720p30
- CVBS inputPAL/NTSC
- Two-way audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- Analog video input8-ch;Balun interface, supporting coaxitron connection
- AHD input1080p25, 1080p30, 720p25, 720p30
- CVBS outputN/A
- HDMI/VGA output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Network
- Network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
- Remote connections128
- Network interface
1,RJ45 10M/100M self-adaptive
Ethernet interface
- Auxiliary interface
- CapacityUp to 6 TB capacity for each disk
- Serial interfaceN/A
- USB interfaceRear panel: 2 × USB 2.0
- Alarm in/outN/A
- SATA1 SATA interface
- General
- Consumption(without HDD)≤ 12 W
- Working humidity10% to 90%
- Power supply12 VDC
- Working temperature-10 °C to +55 °C (+14 °F to +131 °F)
- Dimensions(W × D × H)260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Weights (without HDD)≤ 1 kg (2.2 lb)
