- Camera
- Image Sensor1MP CMOS Image Sensor
- Max. Resolution1296 (H) × 732 (V)
- Min. Illumination0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & NightIR Cut Filter
- Angle AdjustmentPan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type
Fixed Lens;
Angle of View: 70.9°(3.6mm), 92°(2.8mm), 56.7°(6mm)
- Lens MountM12
- Image
- Frame Rate720p@25fps/720p@30fps
- Wide Dynamic Range (WDR)No
- SNR＞62dB
- Interface
- Video Output1 HD analog output
- General
- DimensionΦ89.5 × 69.8 mm(Φ3.52” × 2.75”)
- 280 g
- Operating Condition-40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)
- Power Supply12 VDC±15%
- ConsumptionMax. 4W
- IR RangeUp to 20m
- Approval
- ProtectionIP66
