- Camera
- Image Sensor
1/3″ Progressive Scan CMOS
- Min. Illumination
0.005 Lux @(F1.6, AGC ON), 0 Lux with IR
- Shutter Speed1/3 s to 1/100,000 s
- Slow ShutterYes
- Wide Dynamic Range120 dB
- Day & Night
IR Cut Filter
- Angle Adjustment
Pan: 0° to 355°, tilt: 0° to 70°, rotation: 0° to 355°
- Lens
- Lens Type
Varifocal Lens
- Focal Length & FOV2.8 to 12 mm: horizontal FOV 93° to 30°, vertical FOV 50° to 17°, diagonal FOV 111° to 34°
- Lens Mount
Φ14
- Focus
Auto
- ApertureF1.6
- Optical Zoom
Motorized
- Illuminator
- IR Wavelength850nm
- IR Range
Up to 30 m
- Video
- Max. Resolution2560 × 1440
- Main Stream
50 Hz: 20 fps (2560 × 1440)
25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (2560 × 1440)
30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (1280 × 720,640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720,640 × 480, 640 × 360)
- Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile/Main Profile/High Profile
- H.265 TypeMain Profile
- H.264+
Main stream supports
- H.265+
Main stream supports
- Region of Interest (ROI)
1 fixed region for main stream
- Audio
- Audio Compression
-S: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC
- Audio Bit Rate-S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC)
- Audio Sampling Rate
-S: 8 kHz/16 kHz
- Environment Noise Filtering-S: Yes
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,, NTP, UPnP™, SMTP,IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
- Simultaneous Live View
Up to 6 channels
- API
Open Network Video Interface, ISAPI
- User/Host
Up to 32 users. 3 levels: administrator, operator and user
- Network StorageMicroSD/SDHC/SDXC card (256 GB) local storage
- Client
iVMS-4200, Hik-Connect
- Web Browser
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
- Image
- Image SettingsSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Day/Night Switch
Auto, Schedule, Day, Night
- Image Enhancement
BLC, 3D DNR
- DNR3D DNR
- Interface
- Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
- On-Board StorageBuilt-in memory card slot, support microSD card, up to 256 GB
- Audio-S: 1 input (line in), 1 output (line out)
- Alarm -S: 1 input,1 output
- Reset KeyYes
- Event
- Basic Event Motion detection, video tampering alarm, exception
- General
- Linkage Method
Upload to FTP, notify surveillance center, send email
also supports: upload to memory card, trigger recording, trigger capture
- Camera DimensionØ141 mm × 99.9 mm (5.6″ × 3.9″)
- Package Dimension140 mm × 140 mm × 154 mm (5.5″ × 5.5″ × 6.1″)
- Camera WeightApprox. 820 g (1.8 lb.)
- With Package WeightApprox. 1200 g (2.6 lb.)
- Storage Conditions-30 °C to +60 °C (22 °F to +140 °F), humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 °C to +60 °C (22 °F to +140 °F), humidity 95% or less (non-condensing)
- Language
English, Ukrainian
- General FunctionAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Firmware VersionV5.5.122
- Power Consumption and Current
12VDC, 0.8A, 10W
POE: (802.3af, 36 V to 57 V), 0.32 A to 0.2 A, Max. 11.5W
- Power Supply
12 VDC ± 25%
PoE: (802.3af, class 3)
- Power InterfaceØ5.5 mm coaxial power plug
- Approval
- EMCFCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
- SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
- EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
- Other
IP67 (IEC 60529-2013), IK10 (IEC 62262:2002)
